CABZEUS

Stereo speaker simulator + DI Box.

About the Product

Cabzeus is a algorithm-based  speaker - cabinet - miking  simulator system. Connected direct to your gears this device enables you to obtain the sound of a miked-guitar amp cabinet without the hassle of miking your cabinets. Extending this basic function, we’ve built into Cabzeus a plethora of unique and powerful features that goes beyond simple speaker simulations.


Stereo I/O


Cabzeus has 2 independent channels, each with its own input, thru, and output. Using a special software that we provide you can freely customize the simulation aspects (speaker type, cabinet type, mic placement, etc.) of each channel independently. To help you get the most of your stereo setup, we have also included powerful stereo processing functions such as :

  • adding short delays (0.02 ms to 125 ms) to one of the channel.

  • blending two simulation channels.

  • independent volume and phase control.

 2 Operating Modes :

  • Stereo Cabs : simulates the process of close-miking two independent speaker cabinets. Each simulator channel has its own extensive set of parameters, including speakers and cabinet type selections, mic-placement , blending, phase, and volume, offering rich and versatile simulation scenarios for both live and direct-recording applications.



  • Stereo Mics : simulates the process of capturing the sound from a single speaker cabinet using two microphones, one mic is placed close to the speaker (close-mic) and the other is placed further back in the room (room-mic). An extensive set of controls offers flexible arrangements and powerful means to combine the two microphone signals into huge expansive stereo sounds.

Product Gallery

Balance of Analog and Digital

​Cabzeus uses advanced DSP processing techniques coupled with clean and robust analog ciruit designs which ensures optimal operating headroom and absolutely minimal noise. Each algorithms has been painstakingly hand-crafted and tuned to achieve faithful emulation of popular and proven speakers and cabinets, we literally spent hundreds of hours analyzing speakers data and and equal amount of time reconstructing their responses through complex algorithms.


Speaker & Cab selection

Speakers selections are organized into 4 classes : Guitar, Bass, Gears, and Miscellaneous.


Integrated DI Box


You can connect a wide range of input sources, ranging from your favorite stompboxes, preamps, your head amp's speaker out, to any music player (see Application Ideas). Its stereo balanced outputs are capable of driving long cables straight to mixing console or FOH speakers. These outputs are tolerant to phantom power, they will not be damaged by accidental application of phantom power.

Specification

Key Features

  • Input impedance    : 1 MOhm.

  • Output impedance : 300 Ohm.

  • Sampling rate : 48 KHz.

  • DAC / ADC resolution : 24 bits.

  • Current consumption : ~150 mA.

  • Weight : 0.6 Kg (1.2 lbs).

  • Dimension : 12 (L) x 9 (W) x 5.5 (H) cm

  • Power source requirement : 9VDC (negative center). Power supply is not included.

  • Compact, stereo Speaker / Cabinet simulator + DI Box.

  • 2 inputs - 2 thrus - 2 outputs (balanced)

  • 8 Presets.

  • Input Pads : 0dB (unity), -20dB or -30dB.

  • Independent Mic Position controls.

  • Deep algorithms editing via CabsLab® software.

  • MIDI and External Switch Inputs for remote preset change.

  • Stereo headphone out with volume control.

  • Internal charge pump circuitry boosts 9V supply voltage to 18V for extended headroom.

Demo Video

GFI System: CABZEUS Stereo Speaker Simulator & DI Box
10:57

GFI System: CABZEUS Stereo Speaker Simulator & DI Box

https://www.gfisystem.com/cabzeus.html At the time of writing the Cabzeus FW featured around 40+ excellent cabinet simulations that include guitar, bass, oddities like telephone and megaphones and even simulations of other simulations like the Palmer and RedBox gear. It has built in stereo mic emulation with great short and long reverb and the ability to add a short delay to the cabs for spacial dimension. Each input, left and right, can have a different cab and output assigned to it so you can address two completely different input sources, say, an acoustic and electric guitar. There a headphone output with its own level control, MIDI in to remotely switch the presets and USB connectivity for updates and interfacing with the excellent CabsLab editor. Most of all, it sounds great and will no doubt come in handy an many studio and house desks, pedalboards and the like. As a portable, two-channel, all-in-one cabinet sim solution, the CabZeus is pretty hard to beat. After two days of filming and editing I realise I've probably been pronouncing 'Zeus' incorrectly in this video - it should be 'Zoos'! D'oh! Oh well, I hope you can forgive me for that indiscretion. Today's tools: Guitar: 2017 Ernie Ball Music Man Cutlass SSS (stock). Amp: - Extra effects: Mooer Micro Preamp 008 Cali-MK 3 Cables: Goodwood Audio and Providence Power Supply: Strymon Zuma Mic: Samson Airline77 (me) Camera: Canon 60D (me) and Nikon D5100 (pedal) Soundcard: AVID Mbox Pro 3 (for recording) & Fractal Audio Systems Axe-FX II XL+ (mixing and bouncing). Computer: Apple iMac 27" i7 3.4 GHz 16 GB RAM Software: Logic Pro X, Eventide/Newfangled Audio ‘Elevate’ Mastering Limiter, Apple Final Cut Pro X (video editing and Youtube compression).

Get this pedal now
